愛普生晶振微型的SMD無源晶振用于MPU時鐘Q22FA2380014616，在這個電子產品如日新月異的時代里，產品的更新為我們的生活帶來不少的便利，同時也需要考慮其成本，因此成本問題成了生產商考慮的重要因素，對于把控成本每個企業都有自身的衡量標準，如果超過公司成本范圍，則需要考慮是否找到可替代，低成本的貼片石英晶振,這樣能夠有效節約成本，而工程在設計電路時，又需要考慮其他方面的問題，晶振為何能夠?qū)﹄娮赢a(chǎn)品影響這么大呢？其實我們都知識晶振對于產品本身來說，是具有大價值，而晶振與產品也是相互聯系，缺一不可，同時也說明了晶振對于產品的重要程度。

Product Number16	LxWxH	愛普生晶振型號	Frequency	CL Value	Freq.tol. @+25°C	Freq.tol./Temp.range	Temperature range
Q22FA2380000116	3.2 x 2.5 x 0.7mm	FA-238	20.000000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380000216	3.2 x 2.5 x 0.7mm	FA-238	20.000000 MHz	18 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380001116	3.2 x 2.5 x 0.7mm	FA-238	16.934400 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380001316	3.2 x 2.5 x 0.7mm	FA-238	25.000000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380002216	3.2 x 2.5 x 0.7mm	FA-238	27.000000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380002816	3.2 x 2.5 x 0.7mm	FA-238	27.000000 MHz	18 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380003516	3.2 x 2.5 x 0.7mm	FA-238	20.000000 MHz	12 pF	+/-30 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380004116	3.2 x 2.5 x 0.7mm	FA-238	24.000000 MHz	20 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380004416	3.2 x 2.5 x 0.7mm	FA-238	24.000000 MHz	7 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380004716	3.2 x 2.5 x 0.7mm	FA-238	16.000000 MHz	7 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380004816	3.2 x 2.5 x 0.7mm	FA-238	49.152000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380006316	3.2 x 2.5 x 0.7mm	FA-238	24.576000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380006516	3.2 x 2.5 x 0.7mm	FA-238	24.000000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380007516	3.2 x 2.5 x 0.7mm	FA-238	50.000000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380007616	3.2 x 2.5 x 0.7mm	FA-238	48.000000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380007816	3.2 x 2.5 x 0.7mm	FA-238	48.000000 MHz	18 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380007916	3.2 x 2.5 x 0.7mm	FA-238	27.000000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380008516	3.2 x 2.5 x 0.7mm	FA-238	48.000000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380008816	3.2 x 2.5 x 0.7mm	FA-238	24.576000 MHz	12 pF	+/-30 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380008916	3.2 x 2.5 x 0.7mm	FA-238	24.000000 MHz	16 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C

無源晶振，準確來說應叫Crystal(晶體)，有源晶振則叫Oscillator(振蕩器)。無源晶振是在石英晶片的兩端鍍上電極而成，其兩管腳是無極性的。無源晶振自身無法震蕩，在工作時需要搭配外圍電路。在一定條件下，石英晶片會產生壓電效應：晶片兩端的電場與機械形變會互相轉化。當外加交變電壓的頻率與晶片的固有頻率相等時，晶體產生的振動和電場強度最大，這稱為壓電諧振，類似與LC回路的諧振。

Product Number16	LxWxH	Model	Frequency	CL Value	Freq.tol. @+25°C	Freq.tol./Temp.range	Temperature range
Q22FA2380009116	3.2 x 2.5 x 0.7mm	FA-238	18.432000 MHz	20 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380009216	3.2 x 2.5 x 0.7mm	FA-238	25.000000 MHz	20 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380009316	3.2 x 2.5 x 0.7mm	FA-238	18.432000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380009516	3.2 x 2.5 x 0.7mm	FA-238	25.000000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380009816	3.2 x 2.5 x 0.7mm	FA-238	30.000000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380010316	3.2 x 2.5 x 0.7mm	FA-238	27.000000 MHz	16 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380011416	3.2 x 2.5 x 0.7mm	FA-238	24.000000 MHz	18 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380012016	3.2 x 2.5 x 0.7mm	FA-238	24.576000 MHz	18 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380012716	3.2 x 2.5 x 0.7mm	FA-238	18.432000 MHz	16 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380012816	3.2 x 2.5 x 0.7mm	FA-238	18.432000 MHz	18 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380012916	3.2 x 2.5 x 0.7mm	FA-238	22.579200 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380013316	3.2 x 2.5 x 0.7mm	FA-238	16.000000 MHz	12 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380013716	3.2 x 2.5 x 0.7mm	FA-238	40.000000 MHz	18 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380013816	3.2 x 2.5 x 0.7mm	FA-238	27.000000 MHz	8 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380014016	3.2 x 2.5 x 0.7mm	FA-238	48.000000 MHz	16 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380014116	3.2 x 2.5 x 0.7mm	FA-238	32.000000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380014616	3.2 x 2.5 x 0.7mm	FA-238	26.000000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380014716	3.2 x 2.5 x 0.7mm	FA-238	26.000000 MHz	20 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380014816	3.2 x 2.5 x 0.7mm	FA-238	48.000000 MHz	12 pF	+/-30 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380014916	3.2 x 2.5 x 0.7mm	FA-238	18.432000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
Q22FA2380015616	3.2 x 2.5 x 0.7mm	FA-238	24.576000 MHz	10 pF	+/-50 ppm	+/-30 ppm	-20 to +70 °C
